Integral DD/FS100

Semiconductor » » Trim/Form/Singulation » » Integral DD/FS100

Application
Package: single/dual strand IDF PDip, SOIC, Power TO
Lead: 90 deg Dip, Gull wing, Flat lead.


Specification

  • Input:
    • Slotted FOL magazines or Stack EOL magazines
    • Auto magazines changer
  • Output:
    • Plastic tubes or metal pallet.
    • Auto tubes changer
  • Press:
    • Press #1 servo driven, 3T.
    • Press #2 servo driven, 3T.
    • Press #3 servo driven, 1T.
  • UPH:
    • depend on units per UP (die set design)
    • range from 2000 to 10000
  • Index time: 1.5s (synchronized with press at 40 spm)
  • MTBA: 60 minutes

Toolings material

  • Cutting Punch/Die : Tool steel
  • Stripper : Tool Steel
  • Forming Punch/Cam/Anvil: Tool Steel
  • Optional: Carbide, DLC coating
